Anti-Sialoadhesin/CD169 antibody [HSn 7D2] - BSA and Azide free

• IHC-Fr

Lab

Immunohistochemistry (Frozen sections) - Anti-Sialoadhesin/CD169 antibody [HSn 7D2] - BSA and Azide free (AB269566)

IHC image of Sialoadhesin/CD169 staining in human liver frozen tissue section, fixed in 10% paraformaldehyde (10 min). Staining was performed on a Leica Bond system using the standard protocol F. The section was then incubated with ab18619, 5μg/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX.

For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

This image was produced using the same antibody clone but in a different formulation ab18619, PBS and sodium azide.

• WB

Lab

Western blot - Anti-Sialoadhesin/CD169 antibody [HSn 7D2] - BSA and Azide free (AB269566)

This blot was produced using a 3-8% Tris-Acetate gel under the TA buffer system. The gel was run at 150V for 60 minutes before being transferred onto a Nitrocellulose membrane at 30V for 70 minutes. The membrane was then blocked for an hour using 2% BSA before being incubated with ab269566 overnight at 4°C. Antibody binding was detected using a Goat anti-mouse antibody conjugated to HRP, and visualised using ECL development solution ab133406.

All lanes:

Western blot - Anti-Sialoadhesin/CD169 antibody [HSn 7D2] (<a href='/en-us/products/primary-antibodies/sialoadhesin-cd169-antibody-hsn-7d2-ab18619'>ab18619</a>) at 1 µg/mL

Lane 1:

Human spleen whole tissue lysate at 30 µg

Lane 2:

Human lymph node whole tissue lysate at 30 µg

Secondary

All lanes:

HRP conjugated Goat Anti-Mouse IgG (H+L) at 1/5000 dilution

Predicted band size: 182 kDa

false

Exposure time: 20min
