Anti-SOD2/MnSOD antibody [9E2BD2]

4 product images

•

  Flow Cytometry - Anti-SOD2/MnSOD antibody [9E2BD2] (ab110300)

  HL-60 cells were stained with 1 µg/mL ab110300 in blue or an equal amount of an isotype control antibody (red) and analyzed by flow cytometry.

•

  Immunocytochemistry/ Immunofluorescence - Anti-SOD2/MnSOD antibody [9E2BD2] (ab110300)

  ab110300 staining SOD2 in wild-type HAP1 cells (top panel) and SOD2 knockout HAP1 cells (bottom panel). The cells were fixed with 4% paraformaldehyde (10min), permeabilized with 0.1% Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated with ab110300 at 5ug/ml and Anti-beta Tubulin antibody - Loading Control ab6046 (Tubulin) at 1/1000 dilution overnight at +4°C, followed by a further incubation at room temperature for 1h with a goat secondary antibody to mouse IgG (Alexa Fluor® 488) (Goat Anti-Mouse IgG H&L (Alexa Fluor® 488) preadsorbed ab150117) at 2 μg/ml (shown in green) and a goat secondary antibody to rabbit IgG (Alexa Fluor® 594) (Goat Anti-Rabbit IgG H&L (Alexa Fluor® 594) ab150080) at 2 μg/ml (shown in pseudo color red). Nuclear DNA was labelled in blue with DAPI.


  Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-SOD2/MnSOD antibody [9E2BD2] (ab110300)

  Immunohistochemistry of Superoxide Dismutase 2 in Human cerebellum visualized with ab110300. Superoxide Dismutase 2 immunoactivity is most intense in neuronal cell bodies, most notably in the large Purkinje cells. Note the distinctive subcellular localization of Superoxide Dismutase 2 immunoreactivity in the Purkinje cell bodies.

•

  Immunocytochemistry/ Immunofluorescence - Anti-SOD2/MnSOD antibody [9E2BD2] (ab110300)

  Immunocytochemistry image of Superoxide Dismutase 2 stained Human HDFn cells. The cells were paraformaldehyde fixed (4%, 20 min) and Triton X-100 permeabilized (0.1%, 15min). The cells were incubated with ab110300 at 5 µg/ml for 2h at room temperature or over night at 4°C. The secondary antibody was (red) Alexa Fluor® 594 goat anti-mouse IgG (H+L) used at a 1/1000 dilution for 1h. 10% Goat serum was used as the blocking agent for all blocking steps. DAPI was used to stain the cell nuclei (blue). Target protein locates mainly in mitochondria.
