Rabbit Polyclonal TIMM9 antibody. Suitable for IHC-P, ICC/IF and reacts with Human samples. Immunogen corresponding to Recombinant Full Length Protein corresponding to Human TIMM9.

Be the first to review this product! Submit a review

Images

Immunocytochemistry/ Immunofluorescence - Anti-TIMM9 antibody (AB224320), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TIMM9 antibody (AB224320), expandable thumbnail

Key facts

Isotype
IgG
Host species
Rabbit
Storage buffer

pH: 7.2
Preservative: 0.02% Sodium azide
Constituents: PBS, 40% Glycerol (glycerin, glycerine)

Form
Liquid
Clonality
Polyclonal

Immunogen

  • Recombinant Full Length Protein corresponding to Human TIMM9. Database link Q9Y5J7

Reactivity data

Select an application
Product promiseTestedExpectedPredictedNot recommended
IHC-PICC/IF
Human
Tested
Tested
Mouse
Predicted
Predicted
Rat
Predicted
Predicted
Cow
Predicted
Predicted
Xenopus laevis
Predicted
Predicted

Tested
Tested

Species
Human
Dilution info
1/50.00000 - 1/200.00000
Notes

Perform heat-mediated antigen retrieval with citrate buffer pH 6 before commencing with IHC staining protocol.

Predicted
Predicted

Species
Mouse, Rat, Cow, Xenopus laevis
Dilution info
-
Notes

-

Tested
Tested

Species
Human
Dilution info
0.25000-2.00000 µg/mL
Notes

Fixation/Permeabilization: PFA/Triton X-100.

Predicted
Predicted

Species
Mouse, Rat, Cow, Xenopus laevis
Dilution info
-
Notes

-

Target data

Function

Mitochondrial intermembrane chaperone that participates in the import and insertion of multi-pass transmembrane proteins into the mitochondrial inner membrane. May also be required for the transfer of beta-barrel precursors from the TOM complex to the sorting and assembly machinery (SAM complex) of the outer membrane. Acts as a chaperone-like protein that protects the hydrophobic precursors from aggregation and guide them through the mitochondrial intermembrane space.

Alternative names

Recommended products

Rabbit Polyclonal TIMM9 antibody. Suitable for IHC-P, ICC/IF and reacts with Human samples. Immunogen corresponding to Recombinant Full Length Protein corresponding to Human TIMM9.

Key facts

Isotype
IgG
Form
Liquid
Clonality
Polyclonal
Immunogen
  • Recombinant Full Length Protein corresponding to Human TIMM9. Database link Q9Y5J7
Purification technique
Affinity purification Immunogen
Concentration
Loading...

Storage

Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Avoid freeze / thaw cycle

Supplementary info

This supplementary information is collated from multiple sources and compiled automatically.
Activity summary

TIMM9 also known as TINY TIM9 or TIM9 is a part of the TIMM complex that plays an essential role in mitochondrial protein import. It is a small protein with a molecular mass of approximately 10 kDa. TIMM9 is expressed mainly in mitochondria and is involved in the important process of transferring precursor proteins from the TOM complex to the TIM22 translocase within the inner mitochondrial membrane. This transfer ensures that proteins are correctly integrated and functional within the mitochondrial inner membrane.

Biological function summary

TIMM9 operates as part of the TIMM9-TIMM10 complex which is integral for the import and assembly of mitochondrial carrier proteins. This assembly occurs within the mitochondrial intermembrane space aiding in the continuation of oxidative phosphorylation and energy production by maintaining the mitochondrial carrier proteins’ activity. The TIMM9-TIMM10 complex therefore facilitates the stability and functionality of mitochondrial membranes important for cellular metabolism and energy homeostasis.

Pathways

TIMM9 is significantly involved in the protein translocation pathway specific to mitochondria. It functions closely with the TIM22 translocase serving as an escort for protein precursors. In this pathway TIMM9 collaborates alongside TIMM10 forming an essential step in the translocation of hydrophobic precursor proteins important for mitochondrial activity. This collaboration ensures the integrity of importing key proteins that drive processes like ATP production and metabolic regulation within mitochondria.

Associated diseases and disorders

Mutations or dysfunctions in TIMM9 are linked to mitochondrial disorders that affect energy metabolism. Disorders such as Mitochondrial Encephalomyopathy can arise from a deficiency in the TIMM9-TIMM10 functional complex causing impaired protein import and oxidative phosphorylation. TIMM9 is also interconnected with disorders involving TIMM10 since they jointly facilitate mitochondrial function indicating that disruptions in either protein can lead to related pathophysiological conditions where energy metabolizing tissues like those in the brain and muscles are most affected.

Product promise

We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

In the unlikely event of one of our products not working as expected, you are covered by our product promise.

Full details and terms and conditions can be found here:
Terms & Conditions.

2 product images

  • Immunocytochemistry/ Immunofluorescence - Anti-TIMM9 antibody (ab224320), expandable thumbnail

    Immunocytochemistry/ Immunofluorescence - Anti-TIMM9 antibody (ab224320)

    PFA-fixed/Triton X-100 permeabilized U-251 MG (human brain glioma cell line) cells stained for TIMM9 (green) using ab224320 at 4 μg/ml in ICC/IF.

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TIMM9 antibody (ab224320), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TIMM9 antibody (ab224320)

    Paraffin-embedded human stomach tissue stained for TIMM9 using ab224320 at 1/50 dilution in immunohistochemical analysis.
