Mouse Monoclonal TRPM4 antibody. Suitable for IHC-P, WB and reacts with Human, Dog, African green monkey, Transfected cell lysate - Human samples. Cited in 3 publications. Immunogen corresponding to Recombinant Full Length Protein corresponding to Human TRPM4.

Be the first to review this product! Submit a review

Images

Western blot - Anti-TRPM4 antibody [OTI10H5] (AB123936), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (AB123936), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (AB123936), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (AB123936), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (AB123936), expandable thumbnail

Publications

Key facts

Isotype

IgG1

Host species

Mouse

Storage buffer

pH: 7.3
Preservative: 0.02% Sodium azide
Constituents: PBS, 50% Glycerol (glycerin, glycerine), 1% BSA

Form

Liquid

Clonality

Monoclonal

Immunogen

  • Recombinant Full Length Protein corresponding to Human TRPM4. Database link Q8TD43

Reactivity data

Select an application
Product promiseTestedExpectedPredictedNot recommended
IHC-PWB
Human
Tested
Tested
African green monkey
Expected
Tested
Dog
Expected
Tested
Transfected cell lysate - Human
Not recommended
Tested

Tested
Tested

Species

Human

Dilution info

1/50

Notes

Perform heat-mediated antigen retrieval before commencing with IHC staining protocol.

Expected
Expected

Species

Dog, African green monkey

Dilution info

Use at an assay dependent concentration.

Notes

-

Not recommended
Not recommended

Species

Transfected cell lysate - Human

Dilution info

-

Notes

-

Tested
Tested

Species

Human

Dilution info

1/5000.00000 - 1/10000.00000

Notes

-

Species

Dog

Dilution info

1/5000.00000 - 1/10000.00000

Notes

-

Species

African green monkey

Dilution info

1/5000.00000 - 1/10000.00000

Notes

-

Species

Transfected cell lysate - Human

Dilution info

1/5000.00000 - 1/10000.00000

Notes

-

Associated Products

Select an associated product type

1 product for Alternative Product

Target data

Function

Calcium-activated non selective (CAN) cation channel that mediates membrane depolarization (PubMed:12015988, PubMed:29211723, PubMed:30528822). While it is activated by increase in intracellular Ca(2+), it is impermeable to it (PubMed:12015988). Mediates transport of monovalent cations (Na(+) > K(+) > Cs(+) > Li(+)), leading to depolarize the membrane. It thereby plays a central role in cadiomyocytes, neurons from entorhinal cortex, dorsal root and vomeronasal neurons, endocrine pancreas cells, kidney epithelial cells, cochlea hair cells etc. Participates in T-cell activation by modulating Ca(2+) oscillations after T lymphocyte activation, which is required for NFAT-dependent IL2 production. Involved in myogenic constriction of cerebral arteries. Controls insulin secretion in pancreatic beta-cells. May also be involved in pacemaking or could cause irregular electrical activity under conditions of Ca(2+) overload. Affects T-helper 1 (Th1) and T-helper 2 (Th2) cell motility and cytokine production through differential regulation of calcium signaling and NFATC1 localization. Enhances cell proliferation through up-regulation of the beta-catenin signaling pathway. Plays a role in keratinocyte differentiation (PubMed:30528822).

Alternative names

Transient receptor potential cation channel subfamily M member 4, hTRPM4, Calcium-activated non-selective cation channel 1, Long transient receptor potential channel 4, Melastatin-4, LTrpC-4, LTrpC4, LTRPC4, TRPM4

Recommended products

Mouse Monoclonal TRPM4 antibody. Suitable for IHC-P, WB and reacts with Human, Dog, African green monkey, Transfected cell lysate - Human samples. Cited in 3 publications. Immunogen corresponding to Recombinant Full Length Protein corresponding to Human TRPM4.

Key facts

Isotype

IgG1

Form

Liquid

Clonality

Monoclonal

Immunogen
  • Recombinant Full Length Protein corresponding to Human TRPM4. Database link Q8TD43
Clone number

OTI10H5

Purification technique

Affinity purification

Concentration
Loading...
Purification notes

Purified from cell culture supernatant by affinity chromatography.

Storage

Shipped at conditions

Blue Ice

Appropriate short-term storage duration

1-2 weeks

Appropriate short-term storage conditions

+4°C

Appropriate long-term storage conditions

-20°C

Aliquoting information

Upon delivery aliquot

Storage information

Avoid freeze / thaw cycle

Notes

Clone OTI10H5 (formerly 10H5).

Abcam is leading the way to address reproducibility in scientific research with our highly validated recombinant monoclonal and recombinant multiclonal antibodies. Search & select one of Abcam's thousands of recombinant alternatives to eliminate batch-variability and unnecessary animal use.

If you do not find a host species to meet your needs, our catalogue and custom Chimeric range provides scientists the specificity of Abcam's RabMAbs in the species backbone of your choice. Remember to also review our range of edited cell lines, proteins and biochemicals relevant to your target that may help you further your research goals.

Abcam antibodies are extensively validated in a wide range of species and applications, so please check the reagent specifications meet your scientific needs before purchasing. If you have any questions or bespoke requirements, simply visit the Contact Us page to send us an inquiry or contact our Support Team ahead of purchase.

Supplementary info

This supplementary information is collated from multiple sources and compiled automatically.

Activity summary

TRPM4 also known as Transient Receptor Potential Melastatin 4 is a calcium-activated non-selective cation channel with a mass of approximately 138 kilodaltons. This protein allows the movement of monovalent cations such as sodium across the plasma membrane leading to membrane depolarization. TRPM4 expresses in numerous human tissues including the heart brain and immune cells. Researchers often study this channel to understand its role in cellular electric activities.

Biological function summary

TRPM4 plays an important part in regulating membrane potential and cellular excitability. It does not function as part of a larger structural complex but its activity modulates various cellular processes. For instance it is important in cardiac conduction influencing heart rhythm by affecting the action potential duration. In immune cells TRPM4 contributes to cytokine release and cell movement impacting the body’s inflammatory response.

Pathways

TRPM4's mechanism integrates into significant signaling pathways like the calcium signaling pathway and the cardiac conduction system. Within these pathways its function influences several key proteins. In the calcium signaling pathway TRPM4's activity can affect the function of calmodulin an important calcium sensor while in cardiac cells TRPM4 regulates voltage-gated calcium channels important for heart muscle contraction.

Associated diseases and disorders

TRPM4’s roles associate it with conditions like cardiac arrhythmias and multiple sclerosis. In heart diseases TRPM4 interacts with proteins such as Na+/Ca2+ exchangers and abnormalities in this interaction can lead to arrhythmogenic conditions. For multiple sclerosis studies suggest that altered TRPM4 activity in immune cells impacts the immune response potentially linking it to the disease's progression. Understanding these interactions can provide insights for therapeutic targets.

Product promise

We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

In the unlikely event of one of our products not working as expected, you are covered by our product promise.

Full details and terms and conditions can be found here:
Terms & Conditions.

7 product images

  • Western blot - Anti-TRPM4 antibody [OTI10H5] (ab123936), expandable thumbnail

    Western blot - Anti-TRPM4 antibody [OTI10H5] (ab123936)

    All lanes: Western blot - Anti-TRPM4 antibody [OTI10H5] (ab123936) at 1/5000 dilution

    Lane 1: HepG2 (Human liver hepatocellular carcinoma cell line) cell extract at 35 µg

    Lane 2: HeLa (Human epithelial cell line from cervix adenocarcinoma) cell extract at 35 µg

    Lane 3: HT-29 (Human colorectal adenocarcinoma cell line) cell extract at 35 µg

    Lane 4: A549 (Human lung carcinoma cell line) cell extract at 35 µg

    Lane 5: COS-7 (African green monkey kidney fibroblast-like cell line) cell extract at 35 µg

    Lane 6: Jurkat (Human T cell leukemia cell line from peripheral blood) cell extract at 35 µg

    Lane 7: MDCK (Canine kidney cell line) cell extract at 35 µg

    Lane 8: PC-12 (Rat adrenal gland pheochromocytoma cell line) cell extract at 35 µg

    Lane 9: MCF7 (Human breast adenocarcinoma cell line) cell extract at 35 µg

    Predicted band size: 134 kDa

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (ab123936), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (ab123936)

    Paraffin-embedded human kidney tissue stained for TRPM4 with ab123936 at a 1/50 dilution in immunohistochemical analysis. Heat-induced epitope retrieval by 10 mM citric buffer, pH 6.0, 100°C for 10 minutes.

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (ab123936), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (ab123936)

    Paraffin-embedded human liver tissue stained for TRPM4 with ab123936 at a 1/50 dilution in immunohistochemical analysis. Heat-induced epitope retrieval by 10 mM citric buffer, pH 6.0, 100°C for 10 minutes.

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (ab123936), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (ab123936)

    Paraffin-embedded human liver carcinoma tissue stained for TRPM4 with ab123936 at a 1/50 dilution in immunohistochemical analysis. Heat-induced epitope retrieval by 10 mM citric buffer, pH 6.0, 100°C for 10 minutes.

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (ab123936), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (ab123936)

    Paraffin-embedded human ovary tissue stained for TRPM4 with ab123936 at a 1/50 dilution in immunohistochemical analysis. Heat-induced epitope retrieval by 10 mM citric buffer, pH 6.0, 100°C for 10 minutes.

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (ab123936), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-TRPM4 antibody [OTI10H5] (ab123936)

    Paraffin-embedded human pancreas tissue stained for TRPM4 with ab123936 at a 1/50 dilution in immunohistochemical analysis. Heat-induced epitope retrieval by 10 mM citric buffer, pH 6.0, 100°C for 10 minutes.

  • Western blot - Anti-TRPM4 antibody [OTI10H5] (ab123936), expandable thumbnail

    Western blot - Anti-TRPM4 antibody [OTI10H5] (ab123936)

    All lanes: Western blot - Anti-TRPM4 antibody [OTI10H5] (ab123936) at 1/5000 dilution

    Lane 1: HEK-293T (Human epithelial cell line from embryonic kidney transformed with large T antigen) cells transfected with pCMV6-ENTRY control cDNA at 5 µg

    Lane 2: HEK-293T cells transfected with pCMV6-ENTRY TRPM4 cDNA at 5 µg

    Predicted band size: 134 kDa

Downloads

Product protocols

For this product, it's our understanding that no specific protocols are required. You can:

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
