Anti-Tyrosine Hydroxylase antibody [EP1532Y] - BSA and Azide free

7 product images

•

  Image courtesy of Carl Hobbs, Kings College London, U.K.

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Tyrosine Hydroxylase antibody [EP1532Y] - BSA and Azide free (ab220218)

  Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869 staining Tyrosine Hydroxylase in rat brain tissue sections by Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections). Tissue was fixed with formaldehyde and a heat mediated antigen retrieval step was performed using citrate buffer. Samples were then blocked with 1% B.S.A. for 10 minutes at 21ºC followed by incubation with the primary antibody for 2 hours at 1/1000. A biotin-conjugated goat anti-rabbit polyclonal was used as secondary antibody at a 1/250 dilution.

  This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869).

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Tyrosine Hydroxylase antibody [EP1532Y] - BSA and Azide free (ab220218)

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) analysis of Mouse cerebral cortex tissue sections labeling Tyrosine Hydroxylase with Purified Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869 at 1:500 dilution (1.1 μg/ml). Heat mediated antigen retrieval was performed using Perform heat mediated antigen retrieval using citrate Buffer, PH6. Tissue was counterstained with Hematoxylin. Goat Anti-Rabbit IgG H&L (HRP) ab97051 Goat Anti-Rabbit IgG H&L (HRP) secondary antibody was used at 1:500 dilution. PBS instead of the primary antibody was used as the negative control.

  This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869).

•

  Immunocytochemistry/ Immunofluorescence - Anti-Tyrosine Hydroxylase antibody [EP1532Y] - BSA and Azide free (ab220218)

  Immunocytochemistry/ Immunofluorescence analysis of C6 (Rat glial tumor cell line) cells labeling Tyrosine Hydroxylase with Purified Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869 at 1:100 dilution (5.6μg/ml). Cells were fixed in 4% Paraformaldehyde and permeabilized with 0.1% tritonX-100. Cells were counterstained with Alexa Fluor® 594 Anti-alpha Tubulin antibody [DM1A] - Microtubule Marker ab195889 Anti-alpha Tubulin antibody [DM1A] - Microtubule Marker (Alexa Fluor^® 594) 1:200 (2.5 μg/ml). Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) ab150077 Goat anti rabbit IgG(Alexa Fluor^® 488) was used as the secondary antibody at 1:1000 dilution. DAPI nuclear counterstain. PBS instead of the primary antibody was used as the secondary antibody only control.

  This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869).

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Tyrosine Hydroxylase antibody [EP1532Y] - BSA and Azide free (ab220218)

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) analysis of Rat cerebral cortex tissue sections labeling Tyrosine Hydroxylase with Purified Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869 at 1:500 dilution (1.1 μg/ml). Heat mediated antigen retrieval was performed using Perform heat mediated antigen retrieval using citrate Buffer, PH6. Tissue was counterstained with Hematoxylin. Goat Anti-Rabbit IgG H&L (HRP) ab97051 Goat Anti-Rabbit IgG H&L (HRP) secondary antibody was used at 1:500 dilution. PBS instead of the primary antibody was used as the negative control.

  This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869).

•

  Image courtesy of Carl Hobbs, Kings College London, U.K.

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Tyrosine Hydroxylase antibody [EP1532Y] - BSA and Azide free (ab220218)

  Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869 staining Tyrosine Hydroxylase in mouse brain tissue sections by Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections). Tissue was fixed with formaldehyde and a heat mediated antigen retrieval step was performed using citrate buffer. Samples were then blocked with 1% B.S.A. for 10 minutes at 21ºC followed by incubation with the primary antibody for 2 hours at 1/800. A biotin-conjugated goat anti-rabbit polyclonal was used as secondary antibody at a 1/250 dilution.

  This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869).

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Tyrosine Hydroxylase antibody [EP1532Y] - BSA and Azide free (ab220218)

  This data was developed using the same antibody clone in a different buffer formulation (Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869).

  Immunohistochemical analysis of formalin fixed paraffin embedded mouse brain labelling Tyrosine Hydroxylase antibody with Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869 at a concentration of 0.1µg/ml. The immunostaining was performed on a Ventana DISCOVERY ULTRA (Roche Tissue Diagnostics) instrument with anti-rabbit HQ, anti-HQ HRP followed by ChromoMap DAB IHC Detection Kit. Heat mediated antigen retrieval was performed with DISCOVERY cell conditioning solution (CC1) 100°C, pH8.5 for 32mins.

  Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869 anti-Tyrosine Hydroxylase antibody [EP1532Y] was incubated for 16mins at 37°C. Sections were counterstained with Hematoxylin II. Image inset shows absence of staining in secondary antibody only control.

  Customers are encouraged to optimise antigen retrieval conditions, antibody concentration, incubation times and temperature for best results in their own IHC assay workflow (automated and manual)

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Tyrosine Hydroxylase antibody [EP1532Y] - BSA and Azide free (ab220218)

  This data was developed using the same antibody clone in a different buffer formulation (Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869).

  Immunohistochemical analysis of formalin fixed paraffin embedded human cortex labelling Tyrosine Hydroxylase with Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869 at a concentration of 0.2 µg/ml. The immunostaining was performed on a Ventana DISCOVERY ULTRA (Roche Tissue Diagnostics) instrument with a OptiView DAB IHC Detection Kit. Heat mediated antigen retrieval was performed with DISCOVERY cell conditioning solution (CC1) 100°C, pH8.5 for 32mins.

  Anti-Tyrosine Hydroxylase antibody [EP1532Y] - Neuronal Marker ab137869 anti-Tyrosine Hydroxylase [EP1532Y] was incubated for 16mins at 37°C. Sections were counterstained with Hematoxylin II. Image inset shows absence of staining in secondary antibody only control.

  Customers are encouraged to optimise antigen retrieval conditions, antibody concentration, incubation times and temperature for best results in their own IHC assay workflow (automated and manual)
