Anti-YKL-40/CHI3L1 antibody

• IHC-P

Ap

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-YKL-40/CHI3L1 antibody (AB77528)

IHC image of YKL-40/CHI3L1 staining in Human normal tonsil formalin fixed paraffin embedded tissue section, performed on a Leica Bond™ system using the standard protocol F. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6, epitope retrieval solution 1) for 20 mins. The section was then incubated with ab77528, 1μg/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX.

For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

• ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Anti-YKL-40/CHI3L1 antibody (AB77528)

ab77528 staining Chitinase-3-like protein 1 precursor in U-87 MG cells. The cells were fixed with 100% methanol (5 min), permeabilized with 0.1% PBS-Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1%PBS-Tween for 1h. The cells were then incubated overnight at 4°C with ab77528 at 5µg/ml and ab7291, Mouse monoclonal [DM1A] to alpha Tubulin - Loading Control. Cells were then incubated with ab150081, Goat polyclonal Secondary Antibody to Rabbit IgG - H&L (Alexa Fluor^® 488), pre-adsorbed at 1/1000 dilution (shown in green) and ab150120, Goat polyclonal Secondary Antibody to Mouse IgG - H&L (Alexa Fluor^® 594), pre-adsorbed at 1/1000 dilution (shown in pseudocolour red). Nuclear DNA was labelled with DAPI (shown in blue).

• WB

Lab

Western blot - Anti-YKL-40/CHI3L1 antibody (AB77528)

False colour image of Western blot : Anti-YKL-40/CHI3L1 antibody staining at 1 ug/ml, shown in green; Mouse anti-Alpha Tubulin [DM1A] (ab7291) loading control staining at 1/20000 dilution, shown in red. In Western blot, ab77528 was shown to bind specifically to YKL-40/CHI3L1. A band was observed at 33-42 kDa in wild-type THP-1 cell lysates with no signal observed at this size in CHI3L1 knockout cell line ab280038 (knockout cell lysate ab280097). To generate this image, wild-type and CHI3L1 knockout THP-1 cell lysates were analysed. First, samples were run on an SDS-PAGE gel then transferred onto a nitrocellulose membrane. Membranes were blocked in 3 % milk in TBS-0.1 % Tween^® 20 (TBS-T) before incubation with primary antibodies overnight at 4 °C. Blots were washed four times in TBS-T, incubated with secondary antibodies for 1 h at room temperature, washed again four times then imaged. Secondary antibodies used were Goat anti-Rabbit IgG H&L (IRDye^® 800CW) preabsorbed (ab216773) and Goat anti-Mouse IgG H&L (IRDye^® 680RD) preabsorbed (ab216776) at 1/20000 dilution.

All lanes:

Western blot - Anti-YKL-40/CHI3L1 antibody (ab77528) at 1 µg/mL

Lane 1:

Wild-type THP-1 cell lysate at 20 µg

Lane 2:

CHI3L1 knockout THP-1 cell lysate at 20 µg

Lane 2:

Western blot - Human CHI3L1 knockout THP-1 cell line (<a href='/en-us/products/cell-lines/human-chi3l1-knockout-thp-1-cell-line-ab280038'>ab280038</a>)

Lane 3:

U-87 MG cell lysate at 20 µg

Lane 4:

Jurkat cell lysate at 20 µg

Predicted band size: 43 kDa

Observed band size: 33-42 kDa

false

• WB

Unknown

Western blot - Anti-YKL-40/CHI3L1 antibody (AB77528)

All lanes:

Western blot - Anti-YKL-40/CHI3L1 antibody (ab77528) at 1 µg/mL

All lanes:

THP1 (Human acute monocytic leukemia cell line) Whole Cell Lysate at 10 µg

Secondary

All lanes:

Goat polyclonal to Rabbit IgG - H&L - Pre-Adsorbed (HRP) at 1/3000 dilution

Predicted band size: 43 kDa

Observed band size: 45 kDa

true
