AB227237

Anti-ZAP70 antibody

Be the first to review this product! Submit a review

|

(0 Publication)

Rabbit Polyclonal ZAP70 antibody. Suitable for IP, WB, IHC-P, ICC/IF and reacts with Human samples. Immunogen corresponding to Recombinant Fragment Protein within Human ZAP70.

View Alternative Names

SRK, ZAP70, Tyrosine-protein kinase ZAP-70, 70 kDa zeta-chain associated protein, Syk-related tyrosine kinase

4 Images

Immunocytochemistry/ Immunofluorescence - Anti-ZAP70 antibody (AB227237)

ICC/IF

Supplier Data

Immunocytochemistry/ Immunofluorescence - Anti-ZAP70 antibody (AB227237)

Jurkat (human T cell leukemia cell line from peripheral blood) cells stained for ZAP70 (green) using ab227237 at 1/500 dilution in ICC/IF. Cells were fixed in 4% paraformaldehyde at RT for 15 minutes.

Blue : Hoechst 33342 staining.

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-ZAP70 antibody (AB227237)

IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-ZAP70 antibody (AB227237)

Paraffin-embedded U373 xenograft tissue stained for ZAP70 using ab227237 at 1/500 dilution in immunohistochemical analysis.

Immunoprecipitation - Anti-ZAP70 antibody (AB227237)

IP

Supplier Data

Immunoprecipitation - Anti-ZAP70 antibody (AB227237)

ZAP70 was immunoprecipitated from Jurkat (human T cell leukemia cell line from peripheral blood) whole cell extract with 5 μg ab227237. Western blot was performed from the immunoprecipitate using ab227237.

Lane 1 : Jurkat whole cell extract.

Lane 1 : Control IgG IP in Jurkat whole cell extract.

Lane 2 : ab227237 IP in Jurkat whole cell extract.

All lanes:

Immunoprecipitation - Anti-ZAP70 antibody (ab227237)

Predicted band size: 69 kDa

false

Western blot - Anti-ZAP70 antibody (AB227237)

WB

Supplier Data

Western blot - Anti-ZAP70 antibody (AB227237)

10% SDS-PAGE gel.

All lanes:

Western blot - Anti-ZAP70 antibody (ab227237) at 1/3000 dilution

All lanes:

Jurkat (human T cell leukemia cell line from peripheral blood) whole cell extract at 30 µg

Predicted band size: 69 kDa

false

Key facts

Host species

Rabbit

Clonality

Polyclonal

Isotype

IgG

Carrier free

No

Reacts with

Human

Applications

WB, IP, IHC-P, ICC/IF

Immunogen

Recombinant Fragment Protein within Human ZAP70. The exact immunogen used to generate this antibody is proprietary information.

style

left-column

Alternative Products

Primary Antibodies

AB32429

Anti-ZAP70 antibody [YE291]

20ul selling size|RabMAb|Recombinant

Flow Cytometry (Intracellular) - Anti-ZAP70 antibody [YE291] (AB32429)

0
0

Primary Antibodies

AB199497

Alexa Fluor® 647 Anti-ZAP70 (phospho Y292) antibody [EPR1073]

RabMAb|Recombinant

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-ZAP70 (phospho Y292) antibody [EPR1073] (AB199497)

0
0

Primary Antibodies

AB199245

HRP Anti-ZAP70 (phospho Y292) antibody [EPR1073]

RabMAb|Recombinant

Western blot - HRP Anti-ZAP70 (phospho Y292) antibody [EPR1073] (AB199245)

0
0

Primary Antibodies

AB76501

Anti-ZAP70 (phospho Y292) antibody [EPR1073]

RabMAb|Recombinant

Immunocytochemistry/ Immunofluorescence - Anti-ZAP70 (phospho Y292) antibody [EPR1073] (AB76501)

2
1

Primary Antibodies

AB32410

Anti-ZAP70 antibody [E267]

20ul selling size|RabMAb|Recombinant

Immunocytochemistry/ Immunofluorescence - Anti-ZAP70 antibody [E267] (AB32410)

0
0

Complementary Products

Primary Antibodies

AB237709

Anti-CD8 alpha antibody [CAL66]

BOND RX™ Validated|20ul selling size|RabMAb|Advanced Validation|Recombinant

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD8 alpha antibody [CAL66] (AB237709)

5
2

Primary Antibodies

AB227975

Anti-Lck antibody [EPR20798-107]

RabMAb|Recombinant|KO Validated

Immunocytochemistry/ Immunofluorescence - Anti-Lck antibody [EPR20798-107] (AB227975)

0
0

Primary Antibodies

AB205921

Anti-PD-L1 antibody [28-8]

BOND RX™ Validated|20ul selling size|Recombinant|KO Validated|Advanced Validation|RabMAb

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-PD-L1 antibody [28-8] (AB205921)

4
15

Secondary Antibodies

AB150077

Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488)

Immunocytochemistry/ Immunofluorescence - Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) (AB150077)

5
20

style

left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "IP" : {"fullname" : "Immunoprecipitation", "shortname":"IP"}, "WB" : {"fullname" : "Western blot", "shortname":"WB"}, "IHCP" : {"fullname" : "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections)", "shortname":"IHC-P"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "IP-species-checked": "testedAndGuaranteed", "IP-species-dilution-info": "1/100 - 1/1000", "IP-species-notes": "<p></p>", "WB-species-checked": "testedAndGuaranteed", "WB-species-dilution-info": "1/500 - 1/3000", "WB-species-notes": "<p></p>", "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "1/100 - 1/1000", "IHCP-species-notes": "<p></p>", "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "1/100 - 1/1000", "ICCIF-species-notes": "<p></p>" }, "Mouse": { "IP-species-checked": "predicted", "IP-species-dilution-info": "", "IP-species-notes": "", "WB-species-checked": "predicted", "WB-species-dilution-info": "", "WB-species-notes": "", "IHCP-species-checked": "predicted", "IHCP-species-dilution-info": "", "IHCP-species-notes": "", "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" }, "Rat": { "IP-species-checked": "predicted", "IP-species-dilution-info": "", "IP-species-notes": "", "WB-species-checked": "predicted", "WB-species-dilution-info": "", "WB-species-notes": "", "IHCP-species-checked": "predicted", "IHCP-species-dilution-info": "", "IHCP-species-notes": "", "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" }, "Cow": { "IP-species-checked": "predicted", "IP-species-dilution-info": "", "IP-species-notes": "", "WB-species-checked": "predicted", "WB-species-dilution-info": "", "WB-species-notes": "", "IHCP-species-checked": "predicted", "IHCP-species-dilution-info": "", "IHCP-species-notes": "", "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" } } }

style

left-column

style

left-column

Properties and storage information

Form

Liquid

Purification technique

Affinity purification Immunogen

Storage buffer

pH: 7 Preservative: 0.025% Proclin 300 Constituents: PBS, 20% Glycerol (glycerin, glycerine)

Shipped at conditions

Blue Ice

Appropriate short-term storage duration

1-2 weeks

Appropriate short-term storage conditions

+4°C

Appropriate long-term storage conditions

-20°C

Aliquoting information

Upon delivery aliquot

Storage information

Avoid freeze / thaw cycle

style

left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

ZAP70 also known as Zeta-chain-associated protein kinase 70 is a tyrosine kinase that plays an important role in T-cell receptor signaling. The protein has a molecular mass of approximately 70 kDa. ZAP70 is mainly expressed in T cells and natural killer (NK) cells. It gets activated upon T-cell receptor engagement initiating downstream signaling cascades essential for T-cell function and adaptive immune response.

Biological function summary

ZAP70 is instrumental in the signaling cascade that activates T cells in response to antigen recognition. It forms part of a larger signaling complex following the engagement of the T-cell receptor with antigens. This complex transmits critical activation signals leading to further cellular responses such as cytokine production and cell proliferation. ZAP70's function ensures appropriate immune responses and helps maintain immune system balance.

Pathways

ZAP70 plays an integral role in T-cell receptor signaling pathways. This protein interacts with other signaling molecules like Lck and LAT facilitating the transmission of activation signals within the cell. As part of the T-cell activation pathway ZAP70 helps to bridge receptor-ligand interactions with cellular responses enabling the immune cells to combat infections effectively.

ZAP70 mutations or dysregulations can lead to severe immunodeficiencies or autoimmune diseases. For example ZAP70 deficiency results in severe combined immunodeficiency (SCID) which severely impairs immune function. Additionally aberrant ZAP70 activity has links to certain autoimmune disorders like rheumatoid arthritis where it influences abnormal immune signaling. Understanding the biochemical pathways that involve ZAP70 provides insight into managing these diseases and developing therapeutic strategies.

style

left-column

style

left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:

Visit the General protocols
Visit the Troubleshooting

style

left-column

Target data

Tyrosine kinase that plays an essential role in regulation of the adaptive immune response. Regulates motility, adhesion and cytokine expression of mature T-cells, as well as thymocyte development. Also contributes to the development and activation of primary B-lymphocytes. When antigen presenting cells (APC) activate T-cell receptor (TCR), a serie of phosphorylations lead to the recruitment of ZAP70 to the phosphorylated TCR components CD3E and CD247/CD3Z through ITAM motif at the plasma membrane (PubMed : 7509083). This recruitment serves to localization to the stimulated TCR and to relieve its autoinhibited conformation. Release of ZAP70 active conformation is further stabilized by phosphorylation mediated by LCK. Subsequently, ZAP70 phosphorylates at least 2 essential adapter proteins : LAT and LCP2. In turn, a large number of signaling molecules are recruited and ultimately lead to lymphokine production, T-cell proliferation and differentiation. Furthermore, ZAP70 controls cytoskeleton modifications, adhesion and mobility of T-lymphocytes, thus ensuring correct delivery of effectors to the APC. ZAP70 is also required for TCR-CD247/CD3Z internalization and degradation through interaction with the E3 ubiquitin-protein ligase CBL and adapter proteins SLA and SLA2. Thus, ZAP70 regulates both T-cell activation switch on and switch off by modulating TCR expression at the T-cell surface. During thymocyte development, ZAP70 promotes survival and cell-cycle progression of developing thymocytes before positive selection (when cells are still CD4/CD8 double negative). Additionally, ZAP70-dependent signaling pathway may also contribute to primary B-cells formation and activation through B-cell receptor (BCR).

See full target information ZAP70
