Human IGF1R knockout MCF7 cell line

• WB

Lab

Western blot - Human IGF1R knockout MCF7 cell line (AB287507)

False colour image of Western blot : Anti-IGF1 Receptor antibody [EPR19322] staining at 1/1000 dilution, shown in green; Mouse anti-CANX [CANX/1543] (ab238078) loading control staining at 1/20000 dilution, shown in red. In Western blot, ab182408 was shown to bind specifically to IGF1 Receptor. A band was observed at 82 kDa (beta chain) in wild-type MCF7 cell lysates with no signal observed at this size in IGF1R knockout cell line. To generate this image, wild-type and IGF1R knockout MCF7 cell lysates were analysed. First, samples were run on an SDS-PAGE gel then transferred onto a nitrocellulose membrane. Membranes were blocked in fluorescent western blot (TBS-based) blocking solution before incubation with primary antibodies overnight at 4°C. Blots were washed four times in TBS-T, incubated with secondary antibodies for 1 h at room temperature, washed again four times then imaged. Secondary antibodies used were Goat anti-Rabbit IgG H&L 800CW and Goat anti-Mouse IgG H&L 680RD at 1/20000 dilution.

All lanes:

Western blot - Anti-IGF1 Receptor antibody [EPR19322] (<a href='/ko/products/primary-antibodies/igf1-receptor-antibody-epr19322-ab182408'>ab182408</a>) at 1/1000 dilution

Lane 1:

Wild-type MCF7 cell lysate at 20 µg

Lane 2:

IGF1R knockout MCF7 cell lysate at 20 µg

Lane 3:

HeLa cell lysate at 20 µg

Lane 4:

HDLM-2 cell lysate at 20 µg

Observed band size: 82 kDa

false

• WB

Lab

Western blot - Human IGF1R knockout MCF7 cell line (AB287507)

False colour image of Western blot : Anti-IGF1 Receptor antibody [EPR23027-204] staining at 1/1000 dilution, shown in green; Mouse anti-CANX [CANX/1543] (ab238078) loading control staining at 1/20000 dilution, shown in red. In Western blot, ab263903 was shown to bind specifically to IGF1 Receptor. A band was observed at 105-125 kDa (alpha chain) in wild-type MCF7 cell lysates with no signal observed at this size in IGF1R knockout cell line. To generate this image, wild-type and IGF1R knockout MCF7 cell lysates were analysed. First, samples were run on an SDS-PAGE gel then transferred onto a nitrocellulose membrane. Membranes were blocked in fluorescent western blot (TBS-based) blocking solution before incubation with primary antibodies overnight at 4°C. Blots were washed four times in TBS-T, incubated with secondary antibodies for 1 h at room temperature, washed again four times then imaged. Secondary antibodies used were Goat anti-Rabbit IgG H&L 800CW and Goat anti-Mouse IgG H&L 680RD at 1/20000 dilution.

All lanes:

Western blot - Anti-IGF1 Receptor antibody [EPR23027-204] (<a href='/ko/products/primary-antibodies/igf1-receptor-antibody-epr23027-204-ab263903'>ab263903</a>) at 1/1000 dilution

Lane 1:

Wild-type MCF7 cell lysate at 20 µg

Lane 2:

IGF1R knockout MCF7 cell lysate at 20 µg

Lane 3:

HeLa cell lysate at 20 µg

Lane 4:

HDLM-2 cell lysate at 20 µg

Observed band size: 105-125 kDa

false

• WB

Lab

Western blot - Human IGF1R knockout MCF7 cell line (AB287507)

False colour image of Western blot : Anti-IGF1 Receptor antibody [EPR23027-80] staining at 1/1000 dilution, shown in green; Mouse anti-CANX [CANX/1543] (ab238078) loading control staining at 1/20000 dilution, shown in red. In Western blot, ab263907 was shown to bind specifically to IGF1 Receptor. A band was observed at 105-125 kDa (alpha chain) in wild-type MCF7 cell lysates with no signal observed at this size in IGF1R knockout cell line. To generate this image, wild-type and IGF1R knockout MCF7 cell lysates were analysed. First, samples were run on an SDS-PAGE gel then transferred onto a nitrocellulose membrane. Membranes were blocked in fluorescent western blot (TBS-based) blocking solution before incubation with primary antibodies overnight at 4°C. Blots were washed four times in TBS-T, incubated with secondary antibodies for 1 h at room temperature, washed again four times then imaged. Secondary antibodies used were Goat anti-Rabbit IgG H&L 800CW and Goat anti-Mouse IgG H&L 680RD at 1/20000 dilution.

All lanes:

Western blot - Anti-IGF1 Receptor antibody [EPR23027-80] (<a href='/ko/products/primary-antibodies/igf1-receptor-antibody-epr23027-80-ab263907'>ab263907</a>) at 1/1000 dilution

Lane 1:

Wild-type MCF7 cell lysate at 20 µg

Lane 2:

IGF1R knockout MCF7 cell lysate at 20 µg

Lane 3:

HeLa cell lysate at 20 µg

Lane 4:

HDLM-2 cell lysate at 20 µg

Observed band size: 105-125 kDa

false

• NGS

Lab

Next Generation Sequencing - Human IGF1R knockout MCF7 cell line (AB287507)

182 bp deletion after the Ile55 of the WT protein
