Anti-Filaggrin antibody [EPR21892]

• mIHC

Lab

Multiplex immunohistochemistry - Anti-Filaggrin antibody [EPR21892] (AB221155)

Multiplex immunohistochemistry analysis of formalin/PFA-fixed paraffin-embedded human skin tissue staining Fibrillin 1 with ab315384 at a 1/100 dilution (5.08 μg/ml), ab215853 anti-Aquaporin-3 used at a 1/300 dilution (2.056 μg/ml) and ab221155 anti-Filaggrin used at a 1/1000 dilution (0.497 μg/ml).

Panel A : merged staining of anti-Fibrillin 1 (green; Opal^TM520), anti-Aquaporin-3 (magenta; Opal^TM690) and anti-Filaggrin (gray; Opal^TM570) on human skin.

Panel B : anti-Fibrillin 1 staining extracellular microfibrils in human skin.

Panel C : anti-Aquaporin-3 staining membrane of squamous cells in human skin.

Panel D : anti-Filaggrin staining maturing squamous cells in human skin.

Nuclear DNA was labeled with DAPI (shown in blue).

The section was incubated in three rounds of staining : in the order of ab315384, ab215853 and ab221155 for 30 mins at room temperature. Each round was followed by a separate fluorescent tyramide signal amplification system.

The immunostaining was performed on a Leica Biosystems BOND^® RX instrument with an Opal^TM 4-color kit using Opal Polymer HRP Ms + Rb secondary reagent. Image acquisition was performed with Leica SP8 confocal microscope.

Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins.

• mIHC

Lab

Multiplex immunohistochemistry - Anti-Filaggrin antibody [EPR21892] (AB221155)

Multiplex immunohistochemistry analysis of formalin/PFA-fixed paraffin-embedded human skin tissue staining Filaggrin with ab221155 at a 1/1000 dilution, ab215853 anti-Aquaporin 3 used at an appropriate dilution and ab321976 anti-LAMA3 used at an appropriate dilution.

Panel A : merged staining of anti-Filaggrin (green; Opal^™520), anti-Aquaporin 3 (magenta; Opal^™690) and anti-LAMA3 (gray; Opal^™570) on human skin.

Panel B : anti-Filaggrin staining maturing squamous cells in human skin.

Panel C : anti-Aquaporin 3 staining membrane of squamous cells in human skin.

Panel D : anti-LAMA3 staining epithelial basement membrane in human skin.

Nuclear DNA was labeled with DAPI (shown in blue).

The section was incubated in three rounds of staining : in the order of ab221155, ab215853 and ab321976 for 30 mins at room temperature. Each round was followed by a separate fluorescent tyramide signal amplification system.

The immunostaining was performed on a Leica Biosystems BOND^® RX instrument with an Opal^™ 4-color kit using Opal Polymer HRP Ms + Rb secondary reagent. Image acquisition was performed with Leica SP8 confocal microscope.

Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins.

• IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Filaggrin antibody [EPR21892] (AB221155)

Immunohistochemical analysis of paraffin-embedded human skin tissue labeling Filaggrin with ab221155 at 1/1000 dilution followed by a Ready to use Rabbit specific IHC polymer detection kit (ab209101).

Positive staining on human skin.

The primary antibody was incubated for 30 mins at room temperature.

The immunostaining was performed on a Leica Biosystems BOND^® RX instrument

Counterstained with Hematoxylin.

Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins.

• mIHC

Lab

Multiplex immunohistochemistry - Anti-Filaggrin antibody [EPR21892] (AB221155)

Multiplex immunohistochemistry analysis of formalin/PFA-fixed paraffin-embedded human skin staining Collagen VII with ab309143 at a 1/100 dilution, ab307969 anti-Aquaporin 3 used at 1/5000 dilution and ab221155 anti-FLG used at a 1/1000 dilution.

Panel A : merged staining of anti-Collagen VII (green; Opal™520), anti-Aquaporin 3 (magenta; Opal™690) and anti-FLG (gray; Opal™570) on human skin.

Panel B : anti-Collagen VII staining basement membrane in human skin.

Panel C : anti-Aquaporin 3 staining squamous epithelium in human skin.

Panel D : anti-FLG staining maturing squamous cells in human skin.

Nuclear DNA was labeled with DAPI (shown in blue).

The section was incubated in three rounds of staining : in the order of ab309143, ab307969 and ab221155 for 30 mins at room temperature. Each round was followed by a separate fluorescent tyramide signal amplification system.

The immunostaining was performed on a Leica Biosystems BOND® RX instrument with an Opal™ 4-color kit. Image acquisition was performed with Leica SP8 confocal microscope.

Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution2) for 20 mins.

• mIHC

Supplier Data

Multiplex immunohistochemistry - Anti-Filaggrin antibody [EPR21892] (AB221155)

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) analysis of Human skin tissue labelling Aquaporin 3 with ab307969 at 1/5000 dilution (0.094 µg/mL) (B), Loricrin with ab176322 at 1/3000 dilution (0.031 μg/ml) (C) and Filaggrin with ab221155 at 1/2000 dilution (0.523 μg/ml) (D). Opal Polymer HRP Ms + Rb was used as a secondary antibody, and DAPI was used for a nuclear counter stain. Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution2) for 20 mins. Panel A : merged staining of anti-Aquaporin 3 (magenta; Opal™690), anti-Loricrin (green; Opal™520) and anti-Filaggrin (red; Opal™570) on human skin. Panel B : anti-Aquaporin 3 stained on keratinocytes from the stratum basale to the stratum granulosum of the epidermis. Panel C : anti-Loricrin stained on stratum corneum. Panel D : anti-Filaggrin stained on the granular to stratum corneum transition. The section was incubated in three rounds of staining : in the order of ab307969, ab176322, and ab221155 for 30 mins at room temperature. Each round was followed by a separate fluorescent tyramide signal amplification system. The immunostaining was performed on a Leica Biosystems BOND® RX instrument with an Opal™ 4-color kit. Image acquisition was performed with Leica SP8 confocal microscope.

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Filaggrin antibody [EPR21892] (AB221155)

Immunohistochemical analysis of paraffin-embedded human skin tissue labeling Filaggrin with ab221155 at 1/1000 dilution, followed by Goat Anti-Rabbit IgG H&L (HRP) ready to use. Cytoplasmic staining in epidermis of human skin (PMID : 23152869) is observed. Counter stained with Hematoxylin.

Secondary antibody only control : Used PBS instead of primary antibody, secondary antibody is Goat Anti-Rabbit IgG H&L (HRP) ready to use.

Perform heat mediated antigen retrieval using ab93684 (Tris/EDTA buffer, pH 9.0).
