Anti-GCSF Receptor antibody [EPR26507-386]

• mIHC

Lab

Multiplex immunohistochemistry - Anti-GCSF Receptor antibody [EPR26507-386] (AB324569)

Multiplex immunohistochemistry analysis of formalin/PFA-fixed paraffin-embedded human placenta tissue staining GCSF Receptor with ab324569 at a 1/100 dilution, ab316856 anti-EZHIP used at 1/500 dilution and ab324497 anti-CLEC14A used at a 1/1000 dilution.

Panel A : anti-GCSF Receptor (green; Opal™520), anti-EZHIP (magenta; Opal™690) and anti-CLEC14A (gray; Opal™570) on human placenta.

Panel B : anti-GCSF Receptor staining cytoplasm of trophoblast in human placenta.

Panel C : anti-EZHIP staining nucleus in human placenta.

Panel D : anti-CLEC14A staining endothelium in human placenta.

Nuclear DNA was labeled with DAPI (shown in blue).

The section was incubated in three rounds of staining : in the order of ab324569, ab316856 and ab324497 for 30 mins at room temperature. Each round was followed by a separate fluorescent tyramide signal amplification system.

The immunostaining was performed on a Leica Biosystems BOND^® RX instrument with an Opal™ 4-color kit. Image acquisition was performed with Leica SP8 confocal microscope.

Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins.

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GCSF Receptor antibody [EPR26507-386] (AB324569)

Immunohistochemical analysis of paraffin-embedded Human skeletal muscle tissue labeling GCSF Receptor with ab324569 at 1/100 (4.96 ug/ml) dilution, followed by a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101).

Negative control : no staining on human skeletal muscle. The primary antibody was incubated for 30 mins at room temperature.
The immunostaining was performed on a Leica Biosystems BOND® RX instrument

Counterstained with Hematoxylin.

Secondary antibody only control : Secondary antibody is a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101).

Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GCSF Receptor antibody [EPR26507-386] (AB324569)

Immunohistochemical analysis of paraffin-embedded (A) HEK-293T (human epithelial cell line from embryonic kidney) transfected with a CSF3R expression vector containing a Myc-His tag. (B) HEK-293T transfected with empty vector containing a Myc-His tag. tissue labeling GCSF Receptor with ab324569 at 1/2000 (0.248 ug/ml) dilution, followed by a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101).

Positive staining on (A) HEK-293T (human epithelial cell line from embryonic kidney) transfected with a CSF3R expression vector containing a Myc-His tag, no staining on (B) HEK-293T transfected with empty vector containing a Myc-His tag. The primary antibody was incubated for 30 mins at room temperature.
The immunostaining was performed on a Leica Biosystems BOND® RX instrument

Counterstained with Hematoxylin.

Secondary antibody only control : Secondary antibody is a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101).

Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

• Flow Cyt

Supplier Data

Flow Cytometry - Anti-GCSF Receptor antibody [EPR26507-386] (AB324569)

Flow cytometric analysis of Human PBMC (human peripheral blood mononuclear cell, Left) / Human purified neutrophils (Right) cells labelling GCSF Receptor with ab324569 at 1/50 dilution (1ug) (Red) compared with a Rabbit monoclonal IgG (ab172730) (Black) isotype control and an unlabelled control (cells without incubation with primary antibody and secondary antibody).

Goat Anti-Rabbit IgG (Alexa Fluor® 488, ab150081) at 1/5000 dilution was used as the secondary antibody.

Gated on viable cells.
Negative control : Human PBMC (Gated on Lymphoid Cells).

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GCSF Receptor antibody [EPR26507-386] (AB324569)

Immunohistochemical analysis of paraffin-embedded Human placenta tissue labeling GCSF Receptor with ab324569 at 1/100 (4.96 ug/ml) dilution, followed by a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101).

Positive staining on human placenta (PMID : 10473051; PMID : 33415106). The primary antibody was incubated for 30 mins at room temperature.
The immunostaining was performed on a Leica Biosystems BOND® RX instrument

Counterstained with Hematoxylin.

Secondary antibody only control : Secondary antibody is a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101).

Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GCSF Receptor antibody [EPR26507-386] (AB324569)

Immunohistochemical analysis of paraffin-embedded Human liver tissue labeling GCSF Receptor with ab324569 at 1/100 (4.96 ug/ml) dilution, followed by a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101).

Positive staining on immune cells of human liver. The primary antibody was incubated for 30 mins at room temperature.
The immunostaining was performed on a Leica Biosystems BOND® RX instrument

Counterstained with Hematoxylin.

Secondary antibody only control : Secondary antibody is a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101).

Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins
