Anti-MHC Class II antibody [MRC OX-6] - BSA and Azide free

• IHC-P

AbReview18370****

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-MHC Class II antibody [MRC OX-6] - BSA and Azide free (AB237959)

Immunohistochemistical detection of MHC Class II using antibody ab23990 on PFA-fixed rat spleen tissue sections. Antibody diluted at 1/100 and incubated for2 hours in TBS/BSA/Tween/azide. Secondary antibody : anti mouse IgG conjugated to biotin (1/100). After dissection of spleen from PFA-perfused specimen it was sampled and further immersion-fixed for two Hrs. After subsequent immersion in 30% Sucrose, specimens were snap-frozen. Before immunostaining, the 8 micron sections were placed in a 60 degree C oven for 60 mins to enhance adhesion. The submitted image shows white pulp (PALS) and a small area of red pulp (RP-upper left). The Periarteriolar Sheath (PALS) with it's Central Arteriole/artery (CA)shows many positive cells (B-lymphocytes and Macrophages) and negative lymphocytes (T-cells). The Marginal Sinus (MS) is clearly seen between the PALS and the Marginal Zone (MZ). There is a clear Germinal Centre (GS) in this image.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, L-arginine, and sodium azide (ab23990).

This image is courtesy of an abreview submitted by Carl Hobbs, King's College London, United Kingdom

• IHC-P

Unknown

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-MHC Class II antibody [MRC OX-6] - BSA and Azide free (AB237959)

IHC image of MHC Class II staining in Rat normal spleen formalin fixed paraffin embedded tissue section, performed on a Leica BondTM system using the standard protocol F. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6, epitope retrieval solution 1) for 20 mins. The section was then incubated with ab23990, 10μg/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX.

For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, L-arginine, and sodium azide (ab23990).

• ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Anti-MHC Class II antibody [MRC OX-6] - BSA and Azide free (AB237959)

This data was developed using the same antibody clone in a different buffer formulation containing PBS, L-arginine, and sodium azide (ab23990). Immunofluorescent analysis of 4% Paraformaldehyde-fixed, 0.1% TritonX-100 permeabilized Mouse splenocyte cells labelling MHC Class II with ab23990 at 1/100 dilution (10.63 ug/ml), followed by ab150117 Goat Anti-Mouse IgG H&L (Alexa Fluor® 488) preadsorbed antibody at 1/1000 (2 ug/ml) dilution (Green). ab206369 Anti-beta Tubulin rabbit monoclonal antibody (Alexa Fluor® 594) was used at 1/100 dilution (5µg/mL) as counterstain for tubulin (Red). The Nuclear counterstain was DAPI (Blue). Secondary antibody only control : Secondary antibody is ab150117 Goat Anti-Mouse IgG H&L (Alexa Fluor® 488) preadsorbed antibody. Confocal image showing membranous and cytoplasmic staining in subsets of mouse splenocyte . Image was taken with a confocal microscope(Leica-Microsystems, TCS SP8).

• ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Anti-MHC Class II antibody [MRC OX-6] - BSA and Azide free (AB237959)

This data was developed using the same antibody clone in a different buffer formulation containing PBS, L-arginine, and sodium azide (ab23990). Immunofluorescent analysis of 4% Paraformaldehyde-fixed, 0.1% TritonX-100 permeabilized Rat splenocyte cells labelling MHC Class II with ab23990 at 1/100 dilution (10.63 ug/ml), followed by ab150117 Goat Anti-Mouse IgG H&L (Alexa Fluor® 488) preadsorbed antibody at 1/1000 (2 ug/ml) dilution (Green). ab206369 Anti-beta Tubulin rabbit monoclonal antibody (Alexa Fluor® 594) was used at 1/100 dilution (5µg/mL) as counterstain for tubulin (Red). The Nuclear counterstain was DAPI (Blue). Secondary antibody only control : Secondary antibody is ab150117 Goat Anti-Mouse IgG H&L (Alexa Fluor® 488) preadsorbed antibody. Confocal image showing membranous and cytoplasmic staining in subsets of rat splenocyte. Negative control : C6. Image was taken with a confocal microscope(Leica-Microsystems, TCS SP8).
