Anti-SOX1 antibody [EPR23041-60] - BSA and Azide free

• mIHC

Lab

Multiplex immunohistochemistry - Anti-SOX1 antibody [EPR23041-60] - BSA and Azide free (AB263870)

This data was developed using ab242125, the same antibody clone in a different buffer formulation.

Multiplex immunohistochemistry analysis of formalin/PFA-fixed paraffin-embedded rat cerebellum tissue staining SOX1 with ab242125 at a 1/2000 dilution.

Panel A : merged staining of anti-SOX1 (green; Opal^™570), anti-SOX10 (magenta; Opal^™690) and anti-ROR alpha (gray; Opal^™520) on rat cerebellum.

Panel B : anti-SOX1 staining Bergmann glia in rat cerebellum.

Panel C : anti-SOX10 staining glial cells in rat cerebellum.

Panel D : anti-ROR alpha staining Purkinje cell and molecular layers in rat cerebellum.

Nuclear DNA was labeled with DAPI (shown in blue).

The section was incubated in three rounds of staining : in the order of ab242125, ab180862 and ab256799 for 30 mins at room temperature. Each round was followed by a separate fluorescent tyramide signal amplification system using Opal Polymer HRP Ms + Rb (ready to use).

The immunostaining was performed on a Leica Biosystems BOND^® RX instrument with an Opal^™ 4-color kit. Image acquisition was performed with a Leica SP8 confocal microscope.

Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins.

• IHC-P

Unknown

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-SOX1 antibody [EPR23041-60] - BSA and Azide free (AB263870)

Immunohistochemical analysis of paraffin-embedded mouse testis tissue labeling SOX1 with ab242125 at 1/2000 dilution (0.293 μg/ml) followed by a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101).

Negative control : No staining on the mouse testis.

The section was incubated with ab242125 for 15 mins at room temperature. The immunostaining staining was performed on a Leica Biosystems BOND^® RX instrument. Counterstained with hematoxylin.

Secondary antibody only control : Secondary antibody is a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101).

Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 20 mins.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab242125).

• IHC-P

Unknown

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-SOX1 antibody [EPR23041-60] - BSA and Azide free (AB263870)

Immunohistochemical analysis of paraffin-embedded rat cerebellum tissue labeling SOX1 with ab242125 at 1/2000 dilution (0.293 μg/ml) followed by a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101). Nuclear staining on the stem cells in rat cerebellum is observed. The section was incubated with ab242125 for 15 mins at room temperature. The immunostaining staining was performed on a Leica Biosystems BOND^® RX instrument. Counterstained with hematoxylin.

Secondary antibody only control : Secondary antibody is a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101).

Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 20 mins.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab242125).

• IHC-P

Unknown

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-SOX1 antibody [EPR23041-60] - BSA and Azide free (AB263870)

Immunohistochemical analysis of paraffin-embedded mouse hippocampus tissue labeling SOX1 with ab242125 at 1/2000 dilution (0.293 μg/ml) followed by a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101). Nuclear staining on the stem cells in mouse hippocampus is observed (PMID : 22992951). The section was incubated with ab242125 for 15 mins at room temperature. The immunostaining staining was performed on a Leica Biosystems BOND^® RX instrument. Counterstained with hematoxylin.

Secondary antibody only control : Secondary antibody is a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101).

Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 20 mins.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab242125).

• IHC-Fr

Unknown

Immunohistochemistry (Frozen sections) - Anti-SOX1 antibody [EPR23041-60] - BSA and Azide free (AB263870)

Immunohistochemical analysis of frozen section of 4% PFA-fixed, 0.2% Triton X-100 permeabilized rat cerebellum tissue labeling SOX1 with ab242125 at 1/100 followed by ab150077 AlexaFluor^®488 Goat anti-Rabbit secondary at 1/1000 dilution (Green). Nuclear staining on rat cerebellum (PMID : 24676388) is observed. The nuclear counterstain is DAPI (Blue).

Secondary antibody only control : Secondary antibody is ab150077 AlexaFluor^®488 Goat anti-Rabbit secondary at 1/1000 dilution.

Heat mediated antigen retrieval using sodium citrate buffer (10mM citrate pH 6.0 + 0.05% Tween-20).

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab242125).

• IHC-P

Unknown

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-SOX1 antibody [EPR23041-60] - BSA and Azide free (AB263870)

Immunohistochemical analysis of paraffin-embedded mouse cerebellum tissue labeling SOX1 with ab242125 at 1/2000 dilution (0.293 μg/ml) followed by a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101). Nuclear staining on the stem cells in mouse cerebellum is observed (PMID : 24676388). The section was incubated with ab242125 for 15 mins at room temperature. The immunostaining staining was performed on a Leica Biosystems BOND^® RX instrument. Counterstained with hematoxylin.

Secondary antibody only control : Secondary antibody is a ready to use Rabbit specific IHC polymer detection kit HRP/DAB (ab209101).

Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 20 mins.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab242125).

• IHC-Fr

Unknown

Immunohistochemistry (Frozen sections) - Anti-SOX1 antibody [EPR23041-60] - BSA and Azide free (AB263870)

Immunohistochemical analysis of frozen section of 4% PFA-fixed, 0.2% Triton X-100 permeabilized mouse cerebellum tissue labeling SOX1 with ab242125 at 1/100 followed by ab150077 AlexaFluor^®488 Goat anti-Rabbit secondary at 1/1000 dilution (Green). Nuclear staining on mouse cerebellum (PMID : 24676388) is observed. The nuclear counterstain is DAPI (Blue).

Secondary antibody only control : Secondary antibody is ab150077 AlexaFluor^®488 Goat anti-Rabbit secondary at 1/1000 dilution.

Heat mediated antigen retrieval using sodium citrate buffer (10mM citrate pH 6.0 + 0.05% Tween-20).

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab242125).

• mIHC

Lab

Multiplex immunohistochemistry - Anti-SOX1 antibody [EPR23041-60] - BSA and Azide free (AB263870)

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab242125).

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) analysis of Mouse cerebellum tissue labelling SOX1 with ab242125 at 1 : 2000 (0.29 ug/ml) dilution, RoR alpha/RORA with ab256799 at 1 : 800 (0.63 ug/ml) dilution and SOX10 with ab200078 at 1 : 5000 (0.2 ug/ml) followed by a ready to use secondary antibody Opal Polymer HRP Ms + Rb.

Panel A : merged staining of anti-SOX1 (magenta; Opal^™690), anti-RORA (green; Opal^™520) and anti-SOX10 (gray; Opal^™570) on mouse cerebellum.
Panel B : anti-SOX1 staining Bergmann glia in mouse cerebellum.
Panel C : anti-RORA staining Pukinje cell and molecular layers in mouse cerebellum.
Panel D : anti-SOX10 staining glial cells in mouse cerebellum.
Nuclear DNA was labeled with DAPI (shown in blue).

The section was incubated in three rounds of staining : in the order of ab242125, ab256799 and ab200078 for 30 mins at room temperature. Each round was followed by a separate fluorescent tyramide signal amplification system.

The immunostaining was performed on a Leica Biosystems BOND^® RX instrument with an Opal^™ 4-color kit. Image acquisition was performed with Leica SP8 confocal microscope.

Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution2) for 20 mins
